Novsight 3 Inch Pods Off-road Series Overview

Novsight focuses on the research and development of automotive LED lighting products, bringing you high-quality, high-performance LED pod lights. 3 Inch LED Pod Light adopted with TIR project optical components and custom-designed top-level optical chips, for more stability and brightness.

Designed for adventurers. Whether sunny or rainy days, day or night, it can provide you with the best illumination and vision.4 sizes can be chosen easily and conveniently to install, durable and has strong performance, bringing you the most advanced off-road experience. If you want to add some highlights and functions to your vehicle, Novsight LED pod light is a choice you can’t miss.

Novsight 3 inch pods are universal and fit most vehicles, such as Jeep, Chevy, Ford, Honda, Toyota, and other off-road and overland brands. They can also be installed on motorcycles, SUVs, ATVs, UTVs, tractors, ditches, or boats for various purposes.

Features

• Top-level premium chips
• Compact design and rigid structure
• Engineered TIR project
• High power and stable output
• IP67 top-rate waterproof

Package including

• 2*LED Pods
• 2*Black Covers
• 2*Amber Covers
• 2*Bottom Mount Brackets
• 4*L-Wrenches
• 6*Screws
• 10*Washers

Note: Novsight offers a full set of installation accessories, no need to buy them separately

4 Size Description of 3 Inch LED Pod Driving light, Fog light, Spotlight and Floodlight

SAE Drive light--auxiliary high beam

3 Inch LED Pod Driving light is a rectangular-shaped beam  ,its beam angle is 8*24 degrees ,that uses TIR lens technology to provide further and wider illumination in front and on the sides of your vehicle, supplementing your high beams. The LED Pod driving lights were certified by SAE regulations for on- and off-road use. Driving light is suitable for use on highways or roads, improving your visibility and safety. If you often drive on long trips or in dark areas, driving light is a great choice.

SAE Fog light--Customized for foggy or hazy days

This LED Pod Fog light also uses TIR lens technology, LUX 416 FT (at 127 meters), but its beam angle is 6*36 degrees and the shape is horizontally wide and vertically narrow, which can provide low-intensity but high penetrating to illumination near the ground, cutting through the glare in fog, snow, rain, etc. This light is very suitable for extreme weather conditions, usually used to replace factory fog lights. It can let you see the road in the fog, improving your safety. The LED Pod driving lights were certified by SAE regulations for on- and off-road use. If you live in an area with frequent fog or rain, fog light is a wise investment for you.

LED Pod Floodlight, using TIR lens technology, 1LUX@147FT(45 m),its beam angle is 65 degrees, is a wide and diffuse beam that provides a large area of illumination around your vehicle, enhancing your peripheral vision. Floodlight is suitable for use in close-range or low-speed situations, allowing you to see details or hazards on the roadside. If you work or camp outdoors, or drive off-road. It can let you see the details or dangers on the roadside, giving you more confidence to face the road ahead.

Spotlight--Suitable for the extremely dark road

This LED Pod Spotlight also uses TIR lens technology, but its beam angle is narrower, only 10 degrees, which can project a long distance, reducing glare and scattering, forming a concentrated and bright spot in front of the vehicle. This light is very suitable for dark or low-visibility situations, such as hunting, exploring, or emergency situations. It can help you see obstacles or targets far away, giving you more control.

 Note:

SAE standard is only applicable to white fog and driving mode. The yellow fog lights/cockpit have the same output standard as the white fog lights designed for on-road and off-road, which will hardly blind the eyes of passers-by

Why choose Novsight 3 inch LED pods?

What is TIR?
TIR (Total Internal Reflection), is a lens design. The working principle of LED Pod light TIR is to use total internal reflection optics (TIR optics) to collect all the light emitted by the LED and only irradiate it where you need it, thereby greatly reducing glare and improving overall efficiency. TIR Optics is a custom lens design that improves the beam pattern, making it more focused and efficient

Hard and sturdy casing

According to the characteristics of outdoor sports, the LED pods use of high-efficiency heat dissipation IP67 hard aluminum shell that can effectively resist strong winds and apply to the turbulence of rugged mountain roads, making your adventure more comfortable

100% Satisfaction Guarantee

√ 45 days return for quality problems

√ 5 years worry-free warranty

√ Free shipping in the US

√ 24/7 hours professional customer support team one to one

White or amber. Which color do you prefer?

All pods lights are provided with two covers, one of which is an amber cover after the cover is closed, it can be switched to an amber light

Most of the light is reflected by the driver as driving in adverse weather conditions, for many years, yellow or amber lights have been the standard for snow and fog lighting. Yellow light is very visible in cloudy conditions with better penetration to minimize glare from snow, ice, and rain

LED Pods Specifications

• Pod Power:20W/Light (4 x 5W LED Chips)
• Driving Light Lumen：3200LM/Light
• Spotlight Lumen：3200LM//Light
• Fog Light Lumen：3200LM//Light
• Floodlight Lumen：3200LM//Light
• Input Voltage:9-36V DC,1.36A@13.2V
• Color Temperature: White/Amber | 6500K/2500K
• Waterproof Ratings: IP68 Weatherproof
• Housing Material: Efficient Heat Dissipation Aluminum Housing
• Scratch-Resistant Hardened Flat PC Lens
• Stainless Steel Mounting Bracket

*Specifications for each pod

Dimension
